M series Manual Stainless Steel Work Positioner
M100S
The Platform Work Positioner is designed to be lightweight and compactable. Ideal for industrial or commercial jobs that require cleanliness. Robust design - 304 grade all stainless steel construction. Platform height is adjustable with a manual hand winch. An auto brake system allows for controlled lowering.
Quantity:
The Platform Work Positioner is designed to be lightweight and compactable. Ideal for industrial or commercial jobs that require cleanliness. Robust design - 304 grade all stainless steel construction. Platform height is adjustable with a manual hand winch. An auto brake system allows for controlled lowering.
| Model | M100S | M100LS | M200S | M200LS | |
| Operation mode | Manual | ||||
| Capacity | (kg) | 100 | 100 | 200 | 200 |
| Load Center | (mm) | 230 | 230 | 230 | 230 |
| Max. Platform Height | (mm) | 1500 | 1500 | 1500 | 1500 |
| Min. Platform Height | (mm) | 130 (PE) / 85 Steel | 130 (PE) / 85 Steel | ||
| Min. Fork Height | (mm) | 30~80 | 30~80 | 30~80 | 30~80 |
| Support Leg Height | (mm) | 110 | 80 | 110 | 80 |
| Support Leg Inner Width | 370(370~600) | ||||
| Platform Size | (mm) | 470×600 (PE or Steel) | 470×600 (PE or Steel) | ||
| Overall Dimensions | (mm) | 840×600×1830 | 840×600×1830 | 870×600×1920 | 870×600×1920 |
| Load Wheel | (mm) | ø75 Universal | ø75 Fixed | ø75 Universal | ø75 Fixed |
| Steeing Wheel | (mm) | ø125 (PU) | ø125 (PU) | ø125 (PU) | ø125 (PU) |
| Net Weight | (kg) | 48 | 50 | 62 | 64 |
