ESZ Electric Mobile Scissor Lift Table Selection Guide
ESZ Electric Mobile Scissor Lift Table Selection Guide
Compare ESZ50, ESZ50D, ESZ80 and ESZ80D by load class, scissor type, working height and electric system.
ESZ specification comparison
The supplied parameter sheet lists four configurations with 500 kg or 800 kg rated load and single- or double-scissor lifting.
| Model | Type | Load | Min. height | Max. height | Weight |
|---|---|---|---|---|---|
| ESZ50 | Single | 500 kg | 460 mm | 990 mm | 203 kg |
| ESZ50D | Double | 500 kg | 465 mm | 1700 mm | 250 kg |
| ESZ80 | Single | 800 kg | 460 mm | 1050 mm | 241 kg |
| ESZ80D | Double | 800 kg | 520 mm | 1850 mm | 293 kg |
All four models list a 1020 × 610 mm table, 24 V/70 Ah battery, 500 W drive-wheel motor, 800 W pump-station motor, 1380 mm overall length, 667 mm outside wheel width and 1165 mm handle height.
Decision 1: Select the 500 kg or 800 kg class
Start with the heaviest regular load rather than the average load. ESZ50 and ESZ50D are the 500 kg options. ESZ80 and ESZ80D are the 800 kg options. Review load center, distribution, platform contact area and required safety margin before final approval.
Decision 2: Select single or double scissor
Single-scissor options reach 990 mm for ESZ50 and 1050 mm for ESZ80. Double-scissor options reach 1700 mm for ESZ50D and 1850 mm for ESZ80D. Choose the configuration from the receiving height and then confirm stability, access space and movement route.
Decision 3: Check the electric system and duty cycle
The parameter sheet lists a 24 V/70 Ah battery, 500 W drive-wheel motor and 800 W pump-station motor across the four models. Confirm the charger, charging location, expected lifting frequency and travel distance per cycle in the final quotation.
Review the working environment
Describe floor condition, aisle width, turning space, pedestrian traffic, load dimensions, receiving height and any ramp, outdoor or uneven-floor requirement. High-rack storage, personnel lifting and rough outdoor travel require a separate equipment review.
Buyer checklist
- Maximum and typical load weight.
- Load dimensions and center of gravity.
- Required minimum and maximum working heights.
- Preferred single- or double-scissor configuration.
- Travel route, floor type and aisle width.
- Lifting frequency and travel distance per cycle.
- Battery charging arrangement and duty cycle.
- Safety documents, training and service support.
FAQ
What is the difference between ESZ50 and ESZ50D?
Both are rated for 500 kg and use the listed 1020 × 610 mm table. ESZ50 is single scissor with a 990 mm maximum height, while ESZ50D is double scissor with a 1700 mm maximum height.
What is the difference between ESZ80 and ESZ80D?
Both are rated for 800 kg. ESZ80 reaches 1050 mm, while ESZ80D reaches 1850 mm in the supplied matrix.
Is the ESZ fully electric?
The supplied product information describes electric lifting and electric travel. The parameter sheet lists a battery, drive-wheel motor and pump-station motor for all four models.
Request an ESZ specification review
Share the load, required height, route, floor and duty cycle with Sinolift.
