Sinolift ESS series Full electric scissor lift table truck
ESS
Quantity:
Overview
Quick Details
- Applicable Industries:Construction works
- After Warranty Service:Online support
- Local Service Location:None
- Showroom Location:None
- Place of Origin:China
- Lift Mechanism:Scissor Lift
- Table Size:1020*610
- Weight:250 kg
- Warranty:1 Year
- After-sales Service Provided:Online support
- Machinery Test Report:Provided
- Video outgoing-inspection:Provided
- Marketing Type:Ordinary Product
- Warranty of core components:1 Year
- Core Components:Motor
- Product name:ESS series Full electric scissor lift table truck
Supply Ability
- Supply Ability 1000 Set/Sets per Month
Packaging & Delivery
- Packaging Details pallet packing
- Port Shanghai / Ninbo
- Lead Time:
Quantity(Sets) 1 - 10 11 - 100 101 - 500 >500 Est. Time(days) 7 14 28 To be negotiated
Product Description
| model | ESS50 | ESS50D | ESS80 | ESS80D | |
| Types | Single scissor | Double scissor | Single scissor | Double scissor | |
| Rated load | kg | 500 | 500 | 800 | 800 |
| Table length | mm | 1020 | 1020 | 1020 | 1020 |
| Table width | mm | 610 | 610 | 610 | 610 |
| Minimum height of table | mm | 460 | 465 | 460 | 520 |
| The highest height of the table | mm | 990 | 1700 | 1050 | 1850 |
| Total handle height | mm | 1165 | 1165 | 1165 | 1165 |
| Vehicle length | mm | 1380 | 1380 | 1380 | 1380 |
| Overall width of outer wheel | mm | 667 | 667 | 667 | 667 |
| Weight | kg | 203 | 250 | 241 | 293 |
| Battery parameters | 24V/70Ah | 24V/70Ah | 24V/70Ah | 24V/70Ah | |
| Motor power (driving wheel) | w | 500 | 500 | 500 | 500 |
| Motor power (pump station) | w | 800 | 800 | 800 | 800 |
Detail Images
