QWA Aluminum Tail Lift
QWA Aluminum Tail Lift
Quantity:
In order to meet the needs of different levels of users, the company exclusively developed the aluminum alloy tail plate in China, and put it on the market in August 2007. It has the characteristics of light weight, high strength, good rust resistance, corrosion resistance, beautiful appearance and so on.
| Model | QWA1.0 | QWA1.5 | QWA2.0 |
| Platform Size(mm) | 1700X1600 | 1800X1600 | 2000x1800 |
| 1800x1600 | 1800x1700 | 2100x1800 | |
| 1800x1700 | 1900x1700 | 2200x1800 | |
| 1900x1700 | Can be customized | Can be customized | |
| Capacity(kg) | 1000 | 1500 | 2000 |
| Self weight(kg) | 250 | 330 | 360 |
| Motor power(kw) | 1.6 | 1.6/2.2/2.5 | 2.2/2.5 |
| Motor | DC12V-24V/100AH-160AH | ||
| Frame arm length(mm) | 600/750/800 | 750/800/900/950 | 900/950 |
| Frame inner width(mm) | 900 | 900/1010 | 900/1010 |
| Height form vehicle box to ground(mm) | 700-1550 | 700-1550 | 700-1550 |
| Average lifting speed(mm/sec) | 60-80 | 60-80 | 60-80 |
| Controllable | Controllable | Controllable | |
| Switch speed(mm/sec) | 10 | 10 | 10 |
| Hydraulic oil | 68# | ||
| platform working angle | 5°-9° | 5°-9° | 5°-9° |
